鋼製電線管：薄鋼電線管（C管）
![[耐食性] [豊富な付属品] 鋼製電線管 外からの衝撃などに対して強く、幅広い範囲で使用可能](img/img_mv.jpg)
![[耐食性] [豊富な付属品] 鋼製電線管 外からの衝撃などに対して強く、幅広い範囲で使用可能](img/img_mv_sp.jpg)
本体
単位：mm / 長さ3.66m
| 品番 | 外径 | 外径 公差 |
厚さ | 長さの 公差 |
質量 kg/本 |
質量 kg/m |
1トン 当たりの 本数 |
1束の 本数 |
1束の 質量kg |
大結束数 | 大結束の 質量kg |
|---|---|---|---|---|---|---|---|---|---|---|---|
| DW119K | 19.1 | ±0.2 | 1.6 | ±5 | 2.53 | 0.691 | 396 | 10 | 25.3 | 400 | 1012.0 |
| DW125K | 25.4 | ±0.2 | 1.6 | ±5 | 3.44 | 0.939 | 291 | 10 | 34.4 | 250 | 860.0 |
| DW131K | 31.8 | ±0.2 | 1.6 | ±5 | 4.36 | 1.190 | 230 | 7 | 30.5 | 175 | 763.0 |
| DW139K | 38.1 | ±0.2 | 1.6 | ±5 | 5.27 | 1.440 | 190 | 5 | 26.4 | 125 | 658.8 |
| DW151K | 50.8 | ±0.2 | 1.6 | ±5 | 7.10 | 1.940 | 141 | 3 | 21.3 | 75 | 532.5 |
| DW163K | 63.5 | ±0.35 | 2.0 | ±5 | 11.10 | 3.030 | 90 | 1 | 11.1 | 50 | 555.0 |
| DW175K | 76.2 | ±0.35 | 2.0 | ±5 | 13.40 | 3.660 | 75 | 1 | 13.4 | 40 | 536.0 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| C63 |
| C75 |
付属品
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| C63 |
| C75 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| C63 |
| C75 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| C63 |
| C75 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| 呼び |
|---|
| C19 |
| C25 |
| C31 |
| C39 |
| C51 |
| 呼び |
|---|
| E19 |
| C19 |
| E25 |
| C25 |
| E31 |
| C31 |
| E39 |
| C39 |
| E51 |
| C51 |
| E63 |
| C63 |
| E75 |
| C75 |
